RS485 XF103 Temperature, Humidity And Pressure Sensor

Product Brief XF103 Temperature, Humidity and Pressure Sensor (Outdoor) is an instrument applied in mutil-field meteorological parameters monitoring. This product indicatively integrates the three standard meteorological parameters, Ambient Temperature, Relative Humidity and Barometric Pressure, in one structure. It realizes 24 hours continuous online monitoring of outdoor meteorological parameters, and output these data to users through digital communication interface all at once.

Send Inquiry

Parameters	Measuring Range	Accuracy	Resolution
Ambient Temperature	-40-85℃	≦±0.3℃ (@25℃, typical)	0.01℃
Relative Humidity	0-100%RH	≦±3%RH (@25℃, 10%-80%RH, typical)	0.01%RH
Barometric Pressure	500-1100hPa	≦±0.3hPa (@25℃, 950hPa-1050hPa)	0.1hPa
Operating Temperature	-40℃-80℃
Output	Standard product with RS485 interface, ModbusRTU; Customizable option SDI-12 (Extra cost apply)
Power Supply	DC9-24V
Level of Protection	IP65
Mounting Manner	Standard Product is sleeve fixed, see product dimension. Optional: flange fixation or bending plate fixation)
Fixed Trestle	Optional: 1.5 meter, or 1.8 meter bracket (extra cost apply)
Cable	3 meter cable line (Optional: 10 meter cable line available for extra cost )

Application

Name: China Best RS485 XF103 Temperature, Humidity And Pressure Sensor Manufacturers, Suppliers, Factory - Cost Price- Yantai
Brand: Yantai
SKU: 202795573

· Meteorological Monitoring

· Micro Environmental Monitoring

· Grid Environment Monitoring

· Agricultural Meteorological Monitoring

· Meteorological Traffic Monitoring

· Photovoltaic Environment Monitoring

· Meteorological Monitoring of Wind Power Generation
