Parameters |
Measuring Range |
Accuracy |
Resolution |
|
Ambient Temperature |
-40-85℃ |
≦±0.3℃ (@25℃, typical) |
0.01℃ |
|
Relative Humidity |
0-100%RH |
≦±3%RH (@25℃, 10%-80%RH, typical) |
0.01%RH |
|
Barometric Pressure |
500-1100hPa |
≦±0.3hPa (@25℃, 950hPa-1050hPa) |
0.1hPa |
|
Operating Temperature |
-40℃-80℃ |
||
|
Output |
Standard product with RS485 interface, ModbusRTU; Customizable option SDI-12 (Extra cost apply) |
||
|
Power Supply |
DC9-24V |
||
|
Level of Protection |
IP65 |
||
|
Mounting Manner |
Standard Product is sleeve fixed, see product dimension. Optional: flange fixation or bending plate fixation) |
||
|
Fixed Trestle |
Optional: 1.5 meter, or 1.8 meter bracket (extra cost apply) |
||
|
Cable |
3 meter cable line (Optional: 10 meter cable line available for extra cost ) |
||
Application
· Meteorological Monitoring
· Micro Environmental Monitoring
· Grid Environment Monitoring
· Agricultural Meteorological Monitoring
· Meteorological Traffic Monitoring
· Photovoltaic Environment Monitoring
· Meteorological Monitoring of Wind Power Generation
