Features
1. Small size and easy installation;
2. The grid adopts immersion gold treatment, which has stronger corrosion resistance;
3. The structure design is reasonable, the service life is long, and the sealing performance is good, which can reach IP67;
4. Long transmission distance and strong anti-interference ability;
5. Various output signals can meet different needs;
Application
It is applicable to the qualitative measurement of external rain and snow (with or without), and can be widely used in the fields of meteorology, ocean, environment, airport, port, agricultural greenhouse and traffic auxiliary measuremen
Techinical Data
|
Parameters |
Used to monitor if it rains or snows |
|
Heating function |
Heating power≤2W |
|
Working condition |
Temperature: －30～70℃;Humidity：10～100%RH(No condensation) |
|
Storage conditions |
Temperatue:－40～80℃;Humidity：10～100%RH(No condensation) |
|
Output |
1: RS485 (standard Modbus RTU protocol, equipment default address: FF) 2: Relay switching value, common terminal, normally open port, normally closed port. 3: Combined output: as above 1 + 2. |
|
Power supply |
DC12～24V |
|
Time for detection to reach stability |
8S |
|
Reaction time |
＜1S |
