RY-CYX Rainfall And Snow Sensor

The usage of RY-CYX rain and snow sensor is qualitative monitoring. The principle is to use the conductive characteristics of rainwater and adopt advanced detection circuits. The surface grid electrode senses the external rain and snow conditions to detect whether there is rain or rain in the external environment. The imported intelligent microprocessor is used inside, which is sensitive in response and high in measurement accuracy. After the product is upgraded, the output signals are diverse, the rain and snow sensor signal output: RS485 digital signal, relay switch (normally open by default) signal.

Send Inquiry

Features

1. Small size and easy installation;

2. The grid adopts immersion gold treatment, which has stronger corrosion resistance;

3. The structure design is reasonable, the service life is long, and the sealing performance is good, which can reach IP67;

4. Long transmission distance and strong anti-interference ability;

5. Various output signals can meet different needs;

Application

It is applicable to the qualitative measurement of external rain and snow (with or without), and can be widely used in the fields of meteorology, ocean, environment, airport, port, agricultural greenhouse and traffic auxiliary measuremen

Techinical Data

Parameters	Used to monitor if it rains or snows
Heating function	Heating power≤2W
Working condition	Temperature: －30～70℃;Humidity：10～100%RH(No condensation)
Storage conditions	Temperatue:－40～80℃;Humidity：10～100%RH(No condensation)
Output	1: RS485 (standard Modbus RTU protocol, equipment default address: FF) 2: Relay switching value, common terminal, normally open port, normally closed port. 3: Combined output: as above 1 + 2.
Power supply	DC12～24V
Time for detection to reach stability	8S
Reaction time	＜1S
