Features
▪ RS485 communication, MODBUS protocol communication (customizable protocol).
▪ High precision, reliable performance, suitable for outdoor weather harsh environment.
▪ Realize parameter collection, optional extended LORA, GPRS, 4G and other wireless methods.
▪ Real-time monitoring , low cost, suitable for grid layout.
▪ Small size, modular design, flexible layout.
▪ 32-bit high-speed processing chip, stable and anti-interference.
▪ CE, ROSH, ISO9001 certificates.
Technical Data
|
Measture Item |
Range |
Resolution |
Accuracy |
|
Atmospheric temperature |
-40-60℃ |
0.01℃ |
±0.3℃ (@25℃,typical) |
|
Atmospheric humidity |
0-100%RH |
0.01%RH |
±3%RH (0-90%RH) |
|
Atmospheric pressure |
300-1100hpa |
0.1hpa |
±0.5hpa(0-30℃) |
|
Rianfall |
0-200mm/h |
0.2mm |
±0.4mm(≤10mm),±4%(＞10mm) |
|
Illuminance |
0-200KLUX |
10LUX |
3% |
|
☆Radiation |
0-2000w/㎡ |
1w/㎡ |
±5% |
|
Principle |
①Temperature and humidity (Switzerland Sensirion digital temperature and humidity sensor) ②Rainfall (tipping bucket type) ③Light (German ROHM digital photosensitive chip) ④Radiation (OSRAM silicon photocell) |
||
|
Output Signal |
RS485 communication, Modbus communication protocol |
||
|
Power Supply |
9-24VDC
|
||
|
fixed form |
A) Sleeve fixed; B)Flange adapter fixed |
||
|
Power consumption |
<10mA@12V
|
||
|
Main material |
ASA engineering plastics |
||
|
Ingress Protection |
IP66 |
||
|
Mounting frame |
1.5m, 3m Pole, 1.8m tripod |
||
|
GPS |
Device tracking and positioning |
||
|
Data Release |
PC,Telephone APP,LED,LCD TV display, etc |
||
Structure Chart
