Measuring range |
Leaf temperature -20~80℃ |
|
Leaf humidity 0~100% |
|
|
Respond time |
＜1s |
|
accuracy |
±1℃(25℃);±5%(25℃,0-50%) |
|
Output |
RS485 ModbusRTU |
|
Working voltage |
DC9~24V |
|
Working current |
17ma(DC12V) |
|
Power Consumption |
DC12V <=0.22W |
|
Standard line length |
3m |
|
stabilization time |
About 10 seconds after power on |
|
Ingress Protection |
IP65 |
WIRING METHOD
output sensor is equipped with a 1.5m four core cable as standard. The cable specification is 0.2mm² Four core shielded cable. The wiring color is defined as:
|
RS485 |
|
|
Red |
Positive pole |
|
Black |
Negative pole |
|
Yellow |
A |
|
Blue |
B |
