WAD200 Gully Irrigation Channel Water RS485 Output Radar Velocity Meter

WAD200 radar current meter is a non-contact flow velocity detection device launched by Yantai. It can be used to monitor the surface flow velocity of natural rivers, open channels, underground pipe networks and other water bodies and assist water treatment operations. The electric wave current meter works in the 24GHz ISM frequency band, adopts the CW method, and can detect the flow velocity information of the water body in real time around the clock, and is not affected by climate, temperature, water vapor on the water surface and pollutants in the water. The product has a built-in efficient back-end processing algorithm, which can accurately obtain the water flow velocity. This product provides three standard physical circuit interfaces: RS232, RS485 (default), 4~20mA.

Send Inquiry

Product Paramenters

Speed range	0.1~15 m/s(related to water flow)
Speed measuring accuracy	±0.01m/s;±1%FS
Resolution	0.01m/s
Effective distance	0.5~30m
Measure time	3-240s
Intervals	1-18000s
Measurement direction	Two-way optional
Automatic Angle Correction	30°-60°
Communication Interface	RS-485/ RS-232/4-20 mA current loop
Interface Communication Parameters	960,8,1,None
Protocol	Custom ASCII/ MODBUS
Working frequency	24.000 ~ 24.250GHz adjustable
Antenna Voltage	Planar Microstrip Array Antenna, 14°× 32°
Working current	+7~28V DC
Operating temperature	Working mode, working current ≤ 120mA@12V Low power consumption (sleep) mode, working current ≤ 1mA@12V
Protection Degree	IP67
	-40 ~60℃
Dimensions(l×w×h)	110×110×43 (mm)
Shell material	Front cover steel (white), rear cover aluminum alloy (black)
