Output |
RS-485, MODBUS/RTU Communication Protocol |
|
|
Measuring method |
2 Electrode contact method |
|
|
Range |
0～2000μS/cm 0~5000μS/cm |
Electrode constant 1.0 |
|
Accuracy |
±1.5%F.S. |
|
|
Resolution |
1μS/cm |
|
|
Working temperature |
0～65℃;＜0.6MPa;High temperature conductivity customization |
|
|
Calibration method |
Two point calibration |
|
|
Response time |
10 second T90 |
|
|
Temperature compensation |
Automatic temperature compensation(PT1000) |
|
|
Power supply |
12 or 24VDC±10%,10mA; |
|
|
Size |
Diameter 30mm; Length 170mm; |
|
|
Protection level |
IP68;Water depth:20m; Other customization |
|
|
Service life |
Sensor 3 year or more |
|
|
Cable |
5m(Default), Or Customization |
|
|
Shell material |
PVC;PEEK; Or Customization |
|
Q1. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.
Q2. How about your delivery time?
A: Generally, it will take 3 to 7 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
