Factory Supply PM2.5 PM10 Dust Particle Sensor Air Quality Meter For Air Quality Monitoring

Details

RY-CPM2510 air quality sensor (outdoor type) is an instrument for outdoor parameter monitoring of atmospheric outdoor PM2.5 and PM10 for the current smart city and smart environmental monitoring field. The product has a beautiful appearance, high integration and powerful functions and it can expand four kinds of pollution gases (CO, NO2, SO2, O3) and H2S, volatile organic pollutants or other meteorological sensors (temperature, humidity, wind speed, wind direction, atmospheric pressure, rainfall or Sun radiation) and so on.

Category

Weather Sensors

Share to

Send Inquiry

Detailed Images

Measture item	Range	Resolution	Accuracy	configuration
PM2.5	0-1000ug/m³	1ug/m³	±（10±10%）（＜500ug/m³）	Standard
PM10	0-1000ug/m³	1ug/m³	±（10±10%）（＜500ug/m³）	Standard
Supply	12-24VDC
Output	RS485,MODBUSRTU Add function：GPS
Fixed form	A) Sleeve fixed； B)Flange adapter fixed
Power consumption	＜1W@12V
Ingress Protection	IP65
Working Environment	Temperature: -40~85℃ Humidity 5~100%RH No condensation
mode of connection	read line：power supply+ black line：power supply- yellow line：RS485+ blue line：RS485-
Main material	ASA
Mounting frame	1.5m, 3m Flange, 1.8m tripod
Extensible parameter	CO、NO2、SO2、O3、H2S、Other meteorological parameters, etc
