XF-C2 Certificate Marine Wind Sensor Used For Boat

The rotation of the propeller generates sine waves, and the frequency of the sine alternating wave is linearly related to the wind speed. The sinusoidal alternating current wave is generated by a speed measuring coil fixed on the wind speed axis and a six level magnetic steel induction. Every rotation of the propeller will inevitably generate three complete sine waves, which are neither too many nor too few. Therefore, the wind speed data reflected by the frequency of the sine waves is stable and accurate.

Send Inquiry

Technical Data

No.	Name	Technical data
		XFC2-2M	XFC2-2L	XFC2-2H	XFC2-2S
1	Wind speed measuring range	0-60m/s		0-100m/s
2	Wind direction measuring range	0-360°
3	Corresponding wind Angle	＜±10°
4	Wind speed accuracy	±（0.5+0.05×V）m/s		±（0.5+0.025×V）m/s	±（0.5+0.05×V）m/s
5	Wind speed starting value	0.5m/s	1.1m/s	1.0m/s
6	Wind speed resolution	0.1m/s	0.2m/s	0.1m/s

APPLICATIONS

* Environmental monitoring

* Bridge & Tunnel

* Solar and wind power generation

* Wind resource assessment

* Automatic weather station

* Agriculture

Install

The XFC2-2L wind sensor can be installed on a one inch (outer diameter 34mm) stainless steel pipe, and the electronic circuit is achieved through terminals inside the electrical box. The original signal is 5 cable cables, two for wind speed and three for wind direction. If the user chooses a circuit conversion board, the circuit conversion board can transmit wind speed and direction data to the main control system through 485 protocol and 422 protocol.
