HCD6816Z Compact Weather Station
HCD6816Z is designed and produced by Handan yunnong intelligent agricultural technology co., LTD. It innovatively realizes the six meteorological standard parameters (T,RH,P,WD,WDIR,Rianfall) through a highly integrated structure, which can realize the 24-hour continuous online monitoring of outdoor meteorological parameters, and output the six parameters to the user at one time through the digital communication interface.In addition, It can be expanded to increase other meteorological and environmental parameters (AQI six parameters:CO, NO2, SO2, O3, PM2.5, PM10).
FEATURES
1,Standard configuration monitoring T,RH,P,WD,WDIR,Rianfall, RS485(MODBUS );
2,High precision, reliable performance, suitable for outdoor weather harsh environment;
3,Parameter collection, optional wireless data collector, automatic data upload network platform, mobile phone client real-time data view;
4,Real-time monitoring of meteorological environmental data, low cost, suitable for grid distribution;
5,Small size, modular design, flexible layout;
6,Optional GPS positioning, device tracking function;
7,Data acquisition adopts 32-bit high-speed processing chip, stable and anti-interference.
TECHNICAL SPECIFICATION
|
Measture item |
Principle |
Range |
Resolution |
Accuracy |
|
Atmospheric temperature |
MEMS |
-40-60℃ |
0.1℃ |
±0.3℃ (@25℃,typical case) |
|
Atmospheric humidity |
MEMS |
0-100%RH |
0.1%RH |
±3%RH (0-90%RH) |
|
Atmospheric pressure |
MEMS |
300-1100hpa |
0.1hpa |
±0.5hpa(0-30℃) |
|
Wind speed |
Ultrasonic |
0-60m/s |
0.01m/s |
(0-30m/s)±0.3m/s或±3%(30-60m/s)±5% |
|
Wind direction |
Ultrasonic |
0-360° |
0.1° |
±2° |
|
Rianfall |
/ |
0-200mm/h |
0.2mm |
Error<5% |
|
|
||||
|
Supply |
12-24VDC, solar power |
|||
|
Output |
RS485(Modbus) |
|||
|
fixed form |
Sleeve fixed; B)Flange adapter fixed |
|||
|
Power consumption |
＜1W@12V |
|||
|
Ingress Protection |
IP66 |
|||
|
Main material |
ASA+engineering plastics |
|||
|
Mounting frame |
1.5m, 3m Flange, 1.8m tripod |
|||
|
GPS |
Device tracking and positioning |
|||
|
Data Release |
PC,Telephone APP,LED,LCD TV display, etc |
|||
