Products

PM2.5/PM10 Monitor With High Accuracy & Real-time
Features
• Measurement parameters are integrated into one multiparameter platform
• Weather parameter hub having analog input options
• Set of 3rd party analog sensors can be connected (Temperature PT1000, solar radiation, water/snow level, tipping bucket)
• Digital interface incorporates also analog input parameters, Analog output options
• Wide variety of digital communication modes
• Wide range of operating and heating voltages, No moving parts, Configuration Tool for PC, Works also with solar panels, USB connectivity, IP68 housing with the mounting kit, Machine-to-machine interface
Specifications
|
Measture item |
Principle |
Range |
Resolution |
Accuracy |
|
Atmospheric temperature |
Energy gap method |
-40-60℃ |
0.01℃ |
±0.3℃(25℃) |
|
Atmospheric humidity |
Capacitance method |
0-100%RH |
0.01% |
±3%RH |
|
PM2.5 |
Laser way |
0-1000μg/m³ |
1μg/m³ |
±10%(<500μg) |
|
PM10 |
Laser way |
0-1000μg/m³ |
1μg/m³ |
±10%(<500μg) |
|
Supply |
12-24VDC |
|||
|
Output |
RS485(Modbus) |
|||
|
fixed form |
Sleeve fixed, flange fixed |
|||
|
Power consumption |
<1w@12V |
|||
|
Ingress Protection |
IP65 |
|||
|
Work Environment |
Temperature: -40-70℃;Humidity: 5-90%RH |
|||
|
Add function |
● data collector (net port, GPRS) ● Fixed brackets (1.5m, 3m) constitute a complete set of monitoring station ●B/S architecture software platform, mobile APP client software (android version only) ● Solar power system |
|||
|
Main material |
ASA+engineering plastics |
|||
|
Mounting frame |
1.5m, 3m Pole, 1.8m tripod |
|||
|
GPS |
Device tracking and positioning |
|||
|
Data Release |
PC,Telephone APP,LED,LCD TV display, etc |
|||
|
Wiring method |
Red: Power+ Black: Power- Yellow: RS485+ Blue: RS485- |
|||

If you interested in this item please message me on whatsapp:+8615127010821 then I can reply you within 1 mins.Let's discuss more details.
Waiting for you.
Best regards,
