RY-FSX Integrated Wind Speed And Direction Sensor

RY-FSX Wind Speed and Direction Sensor measures wind speed and direction at the same time, and adopts digital output interface. The wind cup adopts the structure of three wind cups, which is made of PC material, which has high strength and good starting; the cup body has better balance after dynamic balance processing. The built-in signal processing unit can output the corresponding wind speed signal according to user needs, and the wind direction adopts the design concept of large wind vane The external environment information can be effectively obtained. The shell is made of ASA material, which has good anti-corrosion and anti-corrosion characteristics, which can ensure that the instrument is free from rust in long-term use. At the same time, it is matched with the internal smooth bearing system to ensure the accuracy of information collection.

Send Inquiry

Features

※Wind Speed range:：0-60m/s,Resolution:0.28m/s(Corresponding number of pulses)

※Wind direction range：0-359.9°

※ Anti-electromagnetic interference treatment

※ Using high-performance imported bearings, low rotation resistance, accurate measurement

※ ASA shell, high mechanical strength, high hardness, does not change color, can be used outdoors for a long time

※ The structure and weight of the equipment are carefully designed and distributed, with small moment of inertia and sensitive response

※Output：RS485(ModBusRTU)

Technical Data

Wind Speed
Measuring Range	0-60m/s
Monitoring principle	Hall principle
Accuracy	±(0.3±0.03V) m/s
Resolution	0.3 m/S
Starting wind speed	≤0.6m/s
Wind Direction
Measuring Range	0-360°
Monitoring principle	Hall principle
Accuracy	±3°
Resolution	0.1°
Starting wind speed	≤0.8m/s

Response time	＜1S
Power Supply	DC12V-DC24V
Power consumption	≤200mW
Ambient temperature	-20-80℃
Ambient humidity	0-100 %RH
Output	RS485(ModBusRTU)

Product Picture

product-1-1

After-sales Service

After purchasing the product, we will provide the product manual for reference. If you have any installation problems,If you interested in this item please message me on whatsapp:+8615127010821 then I can reply you within 1 mins.Let's discuss more details.
Waiting for you.
Best regards,
