Feature
Preferred German imported diffused silicon core
304 stainless steel housing
Tetrafluoro material, built-in shielding layer
45° Inclined pressure hole design
Six layers of waterproof ring
Removable structure prevents clogging
Filter
Technical Data
|
Item |
Technical specifications |
|
Range |
0 ~ 0.5m…200mH2O or 0 ~ 5KPa…2MPa |
|
Output |
4-20mA,0-5V,0-10V,RS485 |
|
Supply Voltage |
12-30VDC,24V typ. |
|
Over Pressure |
2×FS |
|
Measuring Medium |
The liquid(not sticky ) compatible with 316 stainless steel |
|
Total Accuracy |
0.1%FS,0.3%FS(0.25%FS),0.5%FS |
|
Long-term Stability |
0.1%FS/year typ.,0.2%FS/year max. |
|
Ingress Protection |
IP68 |
|
Operating Temperature |
-40℃~ +80℃ |
|
Compensating Temperature |
-10℃~ 70℃ |
|
Temperature Drifting |
0.03%FS/℃ typ.,0.05%FS/℃ |
|
Cycle Life |
1*10^8 @25℃ |
|
Main Material |
Sensor:316L,housing:304SS (316L is optional) |
| Cable | Outer material：PUR,Atmospheric pressure compensation cable, Polymer waterproof plug at cable end |
|
Power Consumption |
Current output:(U*0.02)W, Voltage output:(U*0.008)W, Digital output:(U*0.015)W |
|
Load Capacity |
Current output:≤(U-7)/0.02Ω, Voltage output:≥100kΩ |
|
Weight(probe unpacked) |
Approx. 230g |
|
Storage Condition |
10℃-50℃@20%-90%RH |
