Wind Speed

0-60m/s

±(0.3+0.03V)m/s;V≤30m/s

±(0.3+0.05V)m/s; V≥30m/s           (V stands for standard wind speed in a wind tunnel)

0.01m/s

4HZ

Wind Direction

0-359.9°

±3°(when Wind Speed ＜10m/s)

0.1°

4HZ

Operating Temperature

-40℃-80℃

Output

Standard product with RS485 interface, ModbusRTU;

Customizable option SDI-12, NMEA(Extra costs apply)

Maximum Output Frequency

Passive Mode: 1/S  Active Mode: 1/min

Power Supply

DC9-24V

Level of Protection

IP65

Mounting Manner

Standard Product is sleeve fixed (Optional: matching parts, extra costs apply, see Accessory and Parts)

Fixed Trestle

Optional: 1.5 meter, or 1.8 meter bracket (extra cost apply)

Cable

3 meter cable line (Optional: 10 meter cable line available for extra cost )

Customizable Function       (extra costs apply)

NMEA Communication Protocol, ASCII (ASCII compatible for Vaisala), CAN Port (ASCII), Angle of tilt/electronic compass or/and Heating function

Remarks

1. Supplementary Description on Wind Speed, Wind Direction: The wind speed and wind direction is measured through ultrasonic principle, and the data of instantaneous wind speed, instantaneous wind direction, average wind speed and average wind direction may be part of the output. The optional electronic compass is used to mearsure apparent wind speed and direction data, and the optional GPS is used to calculate the true wind speed and direction.

2. XF_PcSoftV1.0: the upper computer reading software, Nong-IoT developed for XF series compact weather station.
