XF700SL 7-in-1 RS485 Weather Station Wind Speed Direction Air Temperature Humidity Pressure Illumination Rainfall Sensors

XF700SL compact weather station integrates seven meteorological parameters, Ambient Temperature, Relative Humidity, Atmospheric Pressure, Wind Speed (Third Generation), Wind Direction (Third Generation), Optical Rainfall and Solar Radiation, in one structure. It realizes 24 hours continuous online monitoring of outdoor meteorological parameters, and output these data to users through digital communication interface all at once.

Send Inquiry

Parameters	Measuring Range	Accuracy	Resolution	Sampling Frequency
Ambient Temperature	-40-85℃	±0.3℃@25℃	0.01℃	1HZ
Relative Humidity	0-100%RH	±3%RH (10%-80%RH, No Condensation)	0.01%RH	1HZ
Wind Speed (Third Generation)	0-40m/s	0.01m/s	±(0.5+0.05V)M/S	10HZ
Wind Direction (Third Generation)	0-359.9°	±5°(Wind Speed ＜10M/S)	0.1°	10HZ
Atmospheric Pressure	500-1100hPa	±0.5hPa(25℃,950-1100hPa)	0.1hPa	1HZ
Optical Rainfall	0-200mm/h	---	0.2mm	1HZ
Solar Radiation	0-2000W/㎡	±5%	1W	1HZ
Operating Temperature	-30℃-70℃
Output	Standard product with RS485 interface, ModbusRTU; Customizable option SDI-12(Extra costs apply)
Maximum Output Frequency	Passive Mode: 1/S Active Mode: 1/min
Power Supply	DC9-24V
Level of Protection	IP65

It has the advantages of high accuracy, fast response time, strong anti-interference ability, serial port output and so on.Users can measure directly through PC or external instruments.

Features

lIntegrated design of multiple sensors,(No need for a receiver )

lDesign of maintenance free system,(Simple installation)

lOpen system protocol

lCommunication interface adopts RS485

lLow-power design

lIndustrial protective shell,( Ensure long-term outdoor use)

lOptional built-in electronic compass, GPRS, GPS, etc.

Inquiry us:

With rich experiences in tackling problems, Renke aims to provide a package of meteorological solutions to your needs, whatever problems you encounter. Renke team always stands by your side. Just click this picture to send us an inquiry, to know more, or get the latest catalog and competitive quotation. Do not hesitate!
