Advantage of RY-CRY/485
· Isolated power supply design, data stability, strong anti-interference ability
· Mature sensor manufacturing process, high reliability
· Good long-term work stability
· Use durable dissolved oxygen electrolyte formula to extend the maintenance cycle
· Digital interface
Technical Date
|
Measurment |
DO value in water |
|
Range |
0-40.00mg/l |
|
Resolution |
0.01mg/l |
|
Temperature range |
-20~60℃ |
|
Sensor type |
Improved primary battery DO sensor |
|
Accuracy |
<0.5mg/l |
|
Output |
RS485 interface*1 |
|
Protocol |
Compatible with standard MODBUS-RTU protocol |
|
communication method |
RS485 9600,8,1,N (default) |
|
ID |
1-255 Default ID: 01 (0x01) |
|
Setting method |
RS485 remote setting calibration and parameters |
|
Power supply |
12VDC |
|
Power consumption |
30mA @12VDC |
Wiring definition
|
Color |
Red |
Black |
Green |
White |
|
Description |
12V+ |
GND |
485A |
485B |
Certificate
