Application
RY-CPM2519 air quality transmitter (outdoor type) can be applied to urban grid environment monitoring and control, smart street lights, scenic environment monitoring, factories or mines, construction sites (dust monitoring on construction sites), urban roads, highways, Public places and other places involved in air quality monitoring.
Technical Data
|
Item |
Range |
Resolution |
Accuracy |
|
PM2.5 |
0-1000ug/m³ |
1ug/m³ |
±（10±10%）（＜500ug/m³） |
|
PM10 |
0-1000ug/m³ |
1ug/m³ |
±（10±10%）（＜500ug/m³） |
|
Temperature |
-40-85℃ |
0.1℃ |
±0.3℃ (@25℃，typical） |
|
Humidity |
0-100%RH |
0.1%RH |
±3%RH (10-80%RH）No condensation |
|
Air Pressure |
300-1100hpa |
0.1hpa |
≦±0.3hPa（@25℃，950hPa-1050hPa）） |
|
Illuminance |
0-200KLUX |
10LUX |
Reading 3% or 1% F.S |
|
Noise |
30-130dB |
0.1dB |
±1.5dB |
|
Dew point temperature |
0-40℃ |
0.1℃ |
≤0.5℃（0℃-30℃，40%RH~100%RH） ＞1℃（＜0℃，＜40%RH） |
|
CO2 |
0-5000PPM |
1PPM |
±70PPM±3% of reading |
|
Power Supply |
DC12V～24V |
||
|
Power consumption |
<1w(12V) |
||
|
Output |
RS485，MODBUSRTU |
||
|
Working Environment |
Temperature: -40～85℃ Humidity 5～100%RH No condensation |
||
|
Installation |
The sleeve is fixed, and flange adapters are optional. |
||
|
Shell Material |
ASA |
||
|
Ingress Protection |
IP65 |
||
The function is mainly to conduct 24-hour continuous online monitoring of conventional pollution factors in the air, and provide the analyzed data to the EPA as a reference for air quality and assist environmental decision-making. In addition, optional hydrogen sulfide, volatile organic pollutants, total suspended particulate matter and other meteorological sensors (wind speed, wind direction, atmospheric pressure, rainfall, sunshine radiation), etc.
