RY-VS09 10000 Ppm RS485 CO2 Carbon Dioxide Detector Sensor

The RY-VS09 CO2 sensor uses a CO2 probe imported from Sweden, with a wide range and strong antistatic ability. It converts the digital change of carbon dioxide content into analog current, voltage, or MODBUS protocol output for measuring ambient CO2 concentration. Widely used in meteorological environment, fresh air system, greenhouse cultivation, breeding, storage, scientific research and other fields.

Send Inquiry

TECHNICAL SPECIFICATION

●Principle：NDIR

●Measuring range：0～5000ppm

●Accuracy：±70ppm ±data3%(Start ABC, general application environment, within the range of 0 ~ 2000ppm, the accuracy that can be achieved after 3 weeks of continuous operation)

●Working voltage： DC12V

●Working current：DC12V <35ma(485) ;DC12V <55ma(current)

●Power Consumption： DC12V <0.42W (485) ;DC12V <0.66W (current)

●Output： RY-VS09 RY-VS09/485 4-20mA RS485modbus

●Load capacity：Current mode output impedance≤500Ω

●Standard line length：1.5m

●Farthest lead wire：Current200m, RS485 100 m

●Working temperature: 0℃～50℃

●Working Humidity：0～100%RH(Sensor is powered)

●Preheating time: < 1 minute

●Ingress Protection：IP65

●Weight：about 200g
