Features
Multi parameter integrated sensor, real-time monitoring
RS485 output, 3m cable
CE, ROSH, ISO9001 certificates.
ASA material, anti-corrosion, non discoloration, light weight and small volume
Technical Data
|
Measture item |
Principle |
Range |
Resolution |
Accuracy |
|
Atmospheric temperature |
Energy gap method |
-40-60℃ |
0.01℃ |
±0.3℃(V=25℃) |
|
Atmospheric humidity |
Capacitance method |
0-100%RH |
0.01% |
±3%RH(10%-80%,No condensation) |
|
PM2.5 |
Laser way |
0-1000μg/m³ |
1μg/m³ |
±(10+10%)(<500μg) |
|
PM10 |
Laser way |
0-1000μg/m³ |
1μg/m³ |
±(10+10%)(<500μg) |
|
CO |
Electrochemical principle |
0-10ppm |
≤10ppb |
±5%F.S |
|
SO2 |
Electrochemical principle |
0-5000ppb |
≤10ppb |
±5%F.S |
|
NO2 |
Electrochemical principle |
0-5000ppb |
≤10ppb |
±5%F.S |
|
O3 |
Electrochemical principle |
0-5000ppb |
≤10ppb |
±5%F.S |
|
Option |
Wind speed, wind direction, atmospheric pressure, rainfall, H2S, noise, sunshine radiation, AQI index, ultraviolet ray, noise |
|||
|
Supply |
12-24VDC |
|||
|
Output |
RS485(Modbus) |
|||
|
fixed form |
Sleeve fixed, flange fixed |
|||
|
Power consumption |
<1w@12V |
|||
|
Ingress Protection |
IP65 |
|||
|
Work Environment |
Temperature: -40-70℃;Humidity: 5-90%RH |
|||
|
Main material |
ASA+engineering plastics |
|||
|
Mounting frame |
1.5m, 3m Pole, 1.8m tripod |
|||
|
GPS |
Device tracking and positioning |
|||
|
Data Release |
PC,Telephone APP,LED,LCD TV display, etc |
|||
Installation notice:
1.Check frequently to ensure that sensors are not interfered with by other operating equipment that may not fully comply with common standards, such as radio/radar transmitters, ship engines, engines, etc.
2. Do not install in the same plane with any radar scanning device, at least 2M above the distance;
3.It is recommended to keep some distance from the surrounding radio receiving antennas;
4.Use the cable recommended by the company;
5.If there is no correct connection after the cable is cut off, or the cable shielding wire is not properly connected, there is no need to create a ground loop, just wire it according to the installation instructions;
6.Ensure the continuous power supply of the equipment during operation;
7.Avoid the flocculation generated by surrounding buildings such as trees, telegraph poles, tall buildings, etc., which can affect the accuracy of ultrasonic anemometer;
