Measure item |
Range |
Accuracy |
Resolution |
|
|
Atmospheric temperature |
-40-85℃ |
±0.3℃ (@25℃,typical case) |
0.01° |
|
|
Atmospheric humidity |
0-100%RH |
±3%RH (10%-80%RH, No Condensation) |
0.01%RH |
|
|
Atmospheric pressure |
300-1100hpa |
±0.5hPa(25℃,950-1100hPa) |
0.1hpa |
|
|
Wind speed |
0-35m/s |
±0.5 m/s(＜10 m/s); 5%(≥10 m/s) |
0.01m/s |
|
|
Wind direction |
0-359.9° |
±5° (Wind Speed ＜5 m/s) |
0.1° |
|
|
optical rainfall |
0.2-4 mm/min |
±10% |
0.2mm |
|
|
Output |
0.96 "OLed (display with backlight Settings); RS485,Modbus RTU; |
|||
|
Power supply |
DC12V,Capacity: 3200mAh battery |
|||
|
Continuous working hours |
Ambient temperature ≥60 hours; @-40℃ for 6 hours; Hibernated standby duration ≥30 days |
|||
|
Operating temperature |
-40℃-60℃ |
|||
|
Level of Protection |
IP65 |
|||
|
Fixed trestle |
Supporting tripod bracket fixed, or hand-held |
|||
|
Update frequency |
1s |
|||
|
Accessories |
Tripod stand, carrying case, hand-held handle, DC12V charger |
|||
|
Wiring |
Red: Positive pole of power supply; Black: Negative pole of power supply; Yellow: RS485A; Blue: RS485B |
|||
|
Working environment |
-40℃~60℃;0-95%RH without condensation |
|||
|
Product size |
height：368,diameter：81mm |
|||
|
Weight |
Armed with the host: 0.8 kg |
|||
|
Size |
Packing Size: 400 MM* 360 MM |
|||
|
Reliability |
MTBF≥3000h |
|||
|
Rated wind velocity |
Not less than 20 m/s (instantaneous wind speed) |
|||
